Ionizing Gun model: 4110 (Korea)

Code: 4110

Ionizing Gun model: 4110

High Frequency AC Piezo Technology
Slim design makes it suitable for installation inside narrow facility

Characteristic

Stable ion balance
Powerful erasure performance
LED on the top of product
Alarm operation using Audio and LED when HV output is bad
Discharge needle replacement and maintenance convenience
Provide monitoring system
Option: Model 4111 IR Operating Air Controller

Origin: Korea

Add product to cart

Ionizing Gun model: 4110

High Frequency AC Piezo Technology
Slim design makes it suitable for installation inside narrow facility

Characteristic

SPECIFICATIONS
Input Voltage	24V DC, 2.2W (Maximum)
Ion Emission	High Frequency AC Piezo (70kHz)
Balance	< ±30V
Discharge Time	± 1000V to ± 100V Less than 1 seconds at 15cm
Emitter Point	Tungsten 99.99%
Alarm	Visual (LED), Audio (Buzzer) at Power Fail
Output Monitoring	FMS Monitoring Interface
Air Pressure	0.1 ~ 0.5 MPa
Air Inlet	6mm diameter
Material	Enclosure: ABS
Material	Bracket: Stainless Steel
Operating Environment	Temperature: 15 ~ 35°C
Operating Environment	Humidity: 35 ~ 85% RH
Dimension	134W x 56H x 25D mm (Stand 134W x 61H x 25D mm)
Weight	90g (Stand Included)
